Vanyar PRO Disc.
FREE Custom Paint available via our Custom Colour Website.
Design your own colour combination and make a very unique bike to set you apart from the peloton.

The Vanyar come standard with the Shimano T47 BB. Let us know if you'd prefer the SRAM DUB bottom bracket, in the notes, when you place your order.

Unapologetic Finesse

The Vanyar Pro UCI Disc 2024, where a confluence of elegance and aerodynamic efficiency has collided to produce a road machine possessing ultimate climbing capabilities, and race sprinting stiffness to tackle the most challenging of terrains. The second generation Vanyar Pro continues the aggressive geometric design of the first generation, but now with an enhanced, sleek, fully integrated cockpit, delivering clean modern lines, improved aerodynamics, and a lighter and stiffer frameset.

Finite Power Balance

Building on the precision and highly responsive traits of its predecessor, Elves Bikes engineers’ edgy design combines the stiffnesses and rigidity required to transition riders’ raw watts into forward motion, unleashing their true and full potential. A steeper seat tube has been designed to position the rider’s weight directly above the crank to boost power transfer, whilst also lowering their frontal profile to reduce wind resistance and increase traction, enhancing performance when accelerating and climbing. The race ready, hill-climbing geometry places the seat tube angle between 73.5 and 75 degrees, whilst positioning the headtube angle between 72 and 73.5 degrees to achieve the ultimate climbing rider stance.

Comfort without Compromise

Our ultimate hillclimber has been developed to fit tyres of up to 30c for better traction and power transfer on the stepper gradients, without compromising the handling, confidence and comfort required for the ultimate thrill of the descent. Further, to ensure that riders are equipped with the vast choices that Elves Bikes are synonymous with, we now provide the option of two seat post lengths, (350mm and 400mm) and two seat post offsets (12mm or 25mm).

Sculpted to Perfection

Perfectly compatible with modern electronic 12 speed groupsets, and sculpted utilising trusted Toray Japanese Carbon Fibre T800 and T1000, with reinforced T1000 stiffness in key areas such as the bottom bracket and headtube, we have prevented power loss caused by flexing during peddling. Elves Bikes have increased the structural integrity through our UCI approved design, resulting in both a visually striking frame that is lighter, stronger, and aesthetically appealing.

Mastered Aesthetics

Combined with our compact AeroEvo handlebars, The Vanyar Pro 2024’s new cutting edge fully integrated design has placed lightweight and aerodynamic design at the forefront of our engineering methodology, making this the lightest UCI approved disc brake frameset Elves Bikes have ever produced. To create increased strength, the bottom bracket has been changed to a press fit BB386 with greater width, whilst the frameset tubes create efficiencies through their aerodynamic shape, by utilising high modulus Toray carbon fibre layering, producing a bike that unites as one with the rider.

Inspired by You

In collaboration with DSD, our design house in Hong Kong, and using the datasets of the pantones our riders have been selecting, The Vanyar Pro UCI Disc 2024 is available in seven beautifully designed standard colours. Our ethos stems from a deep understanding of unmet customer needs, driving our strategic and inclusive decision to ensure that custom painted frames, celebrating individualism, remain highly accessible to all. The Vanyar Pro is no exception, with ten different designs, inspired by our customers, that utilises over sixty different colourways, and 3 decal choices, creating over 100,000 bespoke paint options.

Your Safety First

The Vanyar Pro 2024 has been UCI approved (UCI CODE: 44895) furnishing our riders with the confidence that this model meets the standards required for safety, high-quality, and optimal performance for cyclists as set out by their independent standards. This assures our customers that following rigorous testing, Elves Bikes are proud to carry the UCI mark of excellence that cyclists rely on globally to make an informed choice when purchasing products. Further, the Frameset is both EN 14766 and ISO 4210-6:2023 test standard approved.

Warranty

Elves design philosophy ensures our products are trusted and well respected within the industry in terms of safety and durability. However, to provide our riders with additional security, Elves bikes offer a staggering 5 -Year global warranty on our frames and forks and two years on our wheels, handlebars, and saddles.

Accessories Included

We are delighted to provide complementary accessories to include rider choice of either a T47 Shimano or SRAM DUB compatible bottom bracket. Further as standard, Elves Bikes frameset purchases include one of our headsets, three 10mm integrated handlebar spacers, two standard rear derailleur hangers, and cable routing stem adapter allowing the fitment of standard bars.

The Global Perspective – Sizing

To support Elves Bikes exponential global growth and movement into the western markets, the Vanyar Pro UCI Disc 2024 is available in the following frame sizes; 47cm, 50cm, 53cm, 56cm, 59cm and 62cm. Please refer to the detailed geometry provided to gain further insight.

Why Elves Bikes?

Together, with our valued customers, Elves Bikes are globally transforming the price point for performance. We are committed to creating far greater rider equality through the production of quality products at affordable price points. We do not believe that riders should have to make the difficult choice and compromise between price or quality, at Elves Bikes, we deliver both. We strive to create inclusive opportunities in everything we do, ensuring that our riders globally, can unleash their true cycling potential.

Colours

Matt Piano Black & Glossy Piano Black
Blazing Orange & Elegant Blue
Silver & Chameleon (Green-Gray)
Chameleon (Forest Green) & Champaign Golden
Chameleon (Navy Blue) & Transparent Red
Gun Gray & Chameleon (Black-Red)
White & Tiffany Blue

Custom Colour Paint is available. Design your own with our Custom Paint Website
talk to us and we'll work with you to make your vision come alive.

Expect about and 8 weeks delivery time.

Frames are shipped with Shimano Bottom Bracket, let us know if you'd like SRAM BB when you order.

Vanyar PRO Disc Sizing Guide

Vanyar Pro Disc Geometry Specs


VANYAR PRO DISC 2024 SPECIFICATIONS

FRAME

  • TORAY T800 & T1000 CARBON FIBER

  • SEAT CLAMP: INTEGRATED

  • WEIGHT: FROM 870g UNPAINTED WITH OUT METAL PARTS

  • HEADSET BEARINGS: 1-1/2" x 7mm (UPPER) & 1-1/2' x 8 mm (LOWER)

  • BRAKE: FLAT MOUNT

  • BOTTOM BRACKET: WIDTH 86.5mm

  • ELECTRONIC & MECHANICAL GROUPSET  COMPATIBLE

  • FULL INTERGRATED CABLE ROUTING

  • THRU AXLE: M 12 x 1.5 x 163mm (143)

  • MAX TYRE CLEARANCE: 30c

  • ROTOR SIZE: 140 OR 160mm

SEAT POST

  • MATERIAL: FULL CARBON

  • SEAT POST LENGTH: 350mm for 47/50/53mm, 400mm for 56/59/62mm

  • WEIGHT 200g (350mm) 215g (400mm)

  • CLAMP: SINGLE BOLT PRECISE ADJUSTMENT

  • SADDLE CLAMPS 7 x 7mm METAL RAILS & 7 x 10mm CARBON RAILS

  • OFFSET: 25mm or 12mm OPTIONS

FORK

  • ELVES VANYAR PRO DISC

  • CARBON FIBRE

  • WEIGHT 430g (WITHOUT THRU AXLE

  • OFFSET: 45mm

  • BRAKE: FLAT MOUNT

  • STEERER TUBE LENGTH: 300mm

  • THRU AXLE: M 12 x 1.5 x 121mm

  • ROTOR SIZE 140 & 160mm

ACCESSORIES INCLUDED WITH THE FRAME

  • BOTTOM BRACKET T47 (24R, 29DUB)

  • ELVES HEADSET

  • HANDLEBARS STEM COMPRESSION PLUG

  • INTEGRATED HANDLEBAR SPACERS

  • 2 x STANDARD GEAR MECH HANGER

  • CABLE ROUTING ADAPTOR FOR REGULAR HANDLEBAR STEMS

  • 2 X INTERNAL CABLE DAMPENER

  • CABLE END STOPS AND ADAPTORS FOR MECHANICAL AND ELECTRONIC GROUPSETS

  • COMPUTER MOUNT (WITH FRAME/BAR & FRAME/BARS/WHEEL BUNDLES)

TORQUE VALUES

  • SADDLE RAILS: 10-12Nm

  • INTEGRATED SEAT POST CLAMP: 10-12Nm

  • HANDLEBAR STEM CLAMP BOLTS: 6Nm

  • FRONT DERAILLUER: 3Nm

  • REAR DERAILLEUR: 2.5Nm

  • WATER BOTTLE CAGE MOUNT 3Nm

  • FRONT/READ CALLIPER: 6Nm

  • FORK COMPRESSION PLUG: 10Nm

  • FRONT/REAR THRU AXLE: 6Nm

  • COMPUTER MOUNT: 3Nm

FRAME & WEIGHTS

ALL FRAME WEIGHTS ARE FOR FRAME ONLY WITHOUT PAINT AND WITH OUT ANY METAL PARTS​ +0/-30g

  • 47mm - 870g
  • 50mm - 890g
  • 53mm - 920g
  • 56mm - 950g
  • 59mm - 980g
  • 62mm - 1000g
