Super-light premium carbon aero frame almost 100g lighter than the PRO model. UCI Approved. T1000/T800 carbon fibre. PF30 Press-fit BB and flat mount disc. Di2 & eTap compatible. Available in sizes 46, 49, 50, 52, 54, 56, 59 and 61. Seven colours, plus bespoke custom paint options. 5 year manufacturers warranty on the frame and forks. For this frame we'd suggest sizing down when choosing your EVO frame size and use longer stem, because the EVO frame has a higher stack and short Toptube.

NEW CUSTOM COLOUR DESIGN WEBSITE

Introductory Offer: FREE DIY CUSTOM COLOUR

Go wild and design you own custom painted frame. Use the Elves online website. Design as many colour combinations as you like and when you're happy select the BUY button. Your mock-up will be sent to us at Elves Australia, and we'll send you a payment link.
Jump to the website here.

We do offer Special Order Custom Painting for an extra $250. Choose the Custom Paint and add Special Order Paint. Then send us an email to discuss your order and we'll do you some mock-ups (info@elvesbikesaustralia.com.au)
Click here to add to your Cart.

 Why buy from your Aussie Distro? Easy question, 5-year warranty, and assurance your build will be free from defects.

Get the matching Orome EVO Aerobar to complete your aero setup.
Click here to view the Bars.

Elves frames are made in their own factory, with their own QA team and the frame has been UCI certified.

All Elves frames remain raw, and are painted when ordered. This is a major factor in keeping the costs down. Most manufacturers paint at factories, which causes huge wastage when a colourway fails to meet customer desires.

When you choose a colour, the frame takes about 6-8 weeks to be painted and to be shipped.

We then ship your frame which normally takes a 1 week to 15 days with SpeedPost.

FRAME:
FULL-CARBON (TORAY T800 & T1000 CARBON FIBER)
GEOMETRY: PRO
SEAT CLAMP: INTEGRATED
WEIGHT: 1005G (SIZE 46, UNPAINTED)
HEADSET BEARING: 1-1/2"X7mm LOWER,1-1/2" X7mm UPPER
BRAKE: FLAT MOUNT
BOTTOM BRACKET: PRESS FIT PF30

• PF30-24 for Shimano crank 24mm axle
• PF30-DUB for SRAM 28.99 axle
• PF30-30mm for FSA crank axle (available on request)

ELECTRIC DRIVETRAIN: Di2 & E-TAP COMPATIBLE
EPS MOLDING TECHNOLOGY
FULL INTEGRATED CABLE ROUTING
THRU AXLE DIMENSION: M12X1.5X163 mm
MAX TYRE SIZE: 700CX32C
MAX ROTOR SIZE: UP TO 160MM

Fork
FULL-CARBON FORK
WEIGHT: 415g
OFFSET: 45mm
BRAKE: FLAT MOUNT
STEER TUBE LENGTH: 300mm
THRU AXLE DIMENSION: M12X1.5X121 mm
MAX ROTOR SIZE: UP TO 160MM

Seat Post
LENGTH: 350mm with 20mm Offset
WEIGHT: 250g
SINGLE BOLE PIVOT PRECISE ADJUSTMENTS
SEATPOST: FULL-CARBON
SADDLE CLAMP: 7X7mm SADDLE RAIL CLAMP (7X10mm CLAMP FOR CARBON RAIL INCLUDED)

Certification
UCI APPROVED
BOTH EN 14766 AND ISO 4210-6:2014

Accessories
PF30, CERAMIC BEARINGS BB
ELVES HEADSET = INTEGRATED HANDLEBAR SPACERS
REAR DERAILLEUR HANGER X2

Available Colours:

Black Red Chameleon & Matt Gun Gray
Green Gray Chameleon & Silver
Matt Black & Glossy Black
Brown Lichen Green Chameleon & White
Forest Green Chameleon & Champaign Golden
Sea Mist Green & Matt Peacock Green
Pink Gold & Flamingo Pink
Custom Paint Available Click here to add
